Power Source |
Gas |
Engine |
Kawasaki 4-cycle, OHV, 351 cc, single-cylinder, air-cooled, pressure-lubricated, spin-on oil filter |
Horsepower |
11.5 @ 3,600 rpm; Exceeds SAE J1940 Performance Standards |
Steering |
Self-adjusting, rack and pinion |
Front Suspension |
Independent leaf spring with dual hydraulic shocks |
Seating Capacity |
2 |
Ground Clearance |
4.5 in (11.4 cm) |
Fuel Tank Capacity |
6 gallons (22.7 L) |
Speed Range |
12-15 mph (19.3-24.1 kph) |
Brakes |
Self-adjusting, rear-wheel, mechanical drum |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum I-beam |
Body color |
Matching paint over molded in color |
Front tires |
18 x 8.50-8, 4-ply rated, premium tread |
Rear tires |
18 x 8.50-8, 4-ply rated, premium tread |
Overall Length |
103.5 in (262.9 cm) |
Overall Width |
48 in (121.9 cm) |
Overall Height |
48 in (121.9 cm) |
Wheelbase |
65.5 in (166.4 cm) |
Tread |
34.5 in/38.5 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
658 lb (298.7 kg) |
Vehicle Warranty |
2-year limited |
Ignition |
Electronic with electronic limiter |
Electrical System |
12-volt, 500 cca 105 min reserve |
Rear Suspension |
Leaf springs with dual hydraulic shocks |
Front Body |
ArmorFlex® |
Bed Height |
27.5 in (69.9 cm) |
Bed Capacity |
300 lb (136.1 kg) |
Cargo Bed Size |
37.6 in x 45.1 in x 9.3 in (9.1 ft3) 95.6 cm x 114.6 cm x 23.5 cm |
Instrumentation |
Electronic fuel gauge/hour meter, low oil warning light |
Total Vehicle Capacity |
800 lb (363.2 kg) |
Turning Radius |
8.4 ft (2.6 m) |
Governor |
Automatic ground speed sensing, internally geared-in unitized transaxle |
Governed RPM |
3050 +/- 30 |
Drive Unit |
Unitized transaxle with helical gears |
Rear Body |
All aluminum |
Flat Bed Size |
35.8 in x 44.3 in (90.8 cm x 112.4 cm) |
Outside Radius Circle |
17.5 ft (5.3 m) dia |
Intersecting Aisle Radius |
72 in (182.9 cm) |
Stabilizer Bar |
Yes |
